Hera Specs

SOURCE

  • Light Source: Philips MSD Platinum 300SFlex
  • Lamp Life: 6.000 Hours
  • Control Method: 23 (Lite)/28 (Standard) 2 Channel Control Modes
  • Control: International Standard DMX512
  • Beam Angle: Beam: 2°- 40°

COLORS

  • CMY Color Mixing
  • Color Temperature: 8000K±200K
  • 3 Color Wheels, 12 Colors Total + Open

GOBO

  • 1 Fixed Gobo Wheel: 10 Gobo’s + Open. Gobo Diameter: 6.5MM
  • 1 Rotating Gobo Wheel: 7 Gobo’s + Open. Gobo Diameter: 12.5MM

POWER

  • Input Voltage: 110V~240V AC, 50/60Hz
  • Rated Power: 500W @ 230V

FEATURES

  • CRI: 76
  • Prism: 6- Facet Linear Prism and 8-Facet Prism, Bi-directional Rotation From Slow To Fast
  • Frost: 1 Single-sided Hightransmission Lens
  • Focus: Linear Focus Via DMX
  • Strobe: 0-15 Times Per Second Highspeed Strobe
  • Dimming: 0-100% Linear Dimming
  • Pan: 540° Tilt: 270°. Auto Return Function
  • Cooling system: 9 Cooling Fans. Auto & Silent Cooling Mode
  • Zoom from 2° to 40°
  • Housing: Aluminium, High Temperature/UV Resistant Engineering Plastic
  • Indoor Use Only: IP20

DIMENSION AND WEIGHT

  • Fixture: 363 x 241 x 597 MM
  • Nett Weight: 25KG
