Highly efficient RBL LED Source

Multi-layer glass optic

8 facet circular prism

Iris Specs

Source

  • Light source: RBL LED module
  • Lamp life: 50.000 Hours
  • Luminous flux: 1335 lumen, 161000lux@2.5m
  • Control: remote on/off via DMX
  • Ballast: switching mode power supply

Optical system

  • Beam angle: 2°

X/Y

  • Pan: 630° (2.5 Sec) or 540°(2 Sec), tilt: 265° (1.8 Sec)
  • 16-Bit resolution
  • Auto repositioning

Gobos

  • 17+Open static gobos
  • Real indexable and gobo shaking
  • Distinctive gobo animation effect

Rigging

  • Mounting points: 2 1⁄4-turn locks
  • Omega bracket with 1⁄4-turn quick locks
  • Safety rope

Features

  • DMX channels: 10/12/13/16
  • Perfect RGB color mixing
  • Static gobo wheel: 17+open
  • Motorized focus
  • Full range 0-100% dimmer
  • Various strobe
  • Frost
  • 8 Facets rotating prism
  • RDM function to change DMX address, flip display, reverse X/Y
  • Software upgrade via DMX
  • Hibernation when lost DMX for preset time
  • Indicate temperature info of base, arm and lamp
  • Fan speed auto change according to temperature

Display

  • 2.4 inch LCD display with english/chinese/french/spanish menu
  • Auto lock
  • Flip
  • Back-up communicating ic

Power

  • Max power consumption: 106w
  • Power supply: electronic auto-ranging
  • Input voltage range: 100–240V, 50-60Hz

Dimension and weight

  • Dimensions: 435x299x226mm
  • Packing: 510x370x260mm
  • Net weight: 15 kg
