PURE LUX

Pure power Pure precision Pure Lux

The high-end RGB-A-WW blinder that transforms every scene with unmatched color performance.

The BSL Pure Lux sets a new benchmark for modern blinders. Powered by a 550W RGB-A-WW LED engine, it delivers not only massive output but also exceptional color quality with a CRI ≥93, ensuring flawless skin tones and true broadcast-ready performance. The addition of full RGB provides a complete, versatile color spectrum, enabling both natural rendering and powerful creative effects.

Its advanced optical system and 50° beam produce a wide, uniform projection that elevates any live production or studio environment. The lightweight magnesium-aluminum housing, IP65 rating, and flexible DMX/RDM modes make the Pure Lux ready for any professional application.

With optional accessories — including rigging solutions, barndoors, and diffusion — the Pure Lux can be fully tailored to the desired look. Engineered for reliability, maximum visual impact, and pure creative control.

Specifications

High CRI LED blinder

550 Watt RGB-A-WW LED source

Lightweight & Versatile

PURE LUX Specs

Specs

  • Light Source: Custom COB LED (R 100W, G 100W, B 100W, W 150W, A 100W)
  • Total LED Power: 550 W RGB-A-WW
  • CRI | CCT range: Ra ≥ 93 | 2000K–10000K (±100K)
  • Illuminance: 12,170 lux @1m / 1,638 lux @3m / 625 lux @5m
  • Beam Angle (50%): 50°
  • Field Angle (10%): 87°
  • Strobe Frequency: 0–25 Hz
  • Control Protocols: DMX512 / RDM
  • DMX Channel Modes: 1 / 5 / 8 / 12 / 17 channels
  • Connector: 5 PIN XLR IN/OUT
  • Input Voltage: 100–240V AC, 50/60 Hz
  • Power Consumption: 120W constant / 280W boost
  • Ingress Protection: IP65
  • Cooling System: Active fan cooling
  • Housing Material: Magnesium–aluminium alloy
  • Dimensions and Weight: 195 × 145 × 145 mm & 2.35 kg

Features

  • High-Fidelity Color Performance:
    Produces exceptional color accuracy with a CRI ≥93 for broadcast-ready visuals.
  • Powerful 550W RGB-A-WW Engine:
    Ensures intense output with rich tonal depth and seamless color mixing.
  • IP65 Outdoor Reliability:
    Engineered for all-weather durability in both indoor and outdoor environments.
  • Versatile Control Flexibility:
    Supports DMX512 and RDM with five selectable channel modes for customised workflows.
  • Lightweight Pro-Grade Housing:
    Magnesium–aluminium construction offers exceptional strength with minimal weight.
  • Wide, Even Projection:
    Advanced optics deliver a smooth 50° beam with outstanding uniformity for stage, studio, and architectural use.
