POWERFUL HYBRID BEAM/SPOT/WASH

CMY COLOR MIXING

2-34 DEGREES ZOOM COVERAGE

Zeus Specs

Source

  • Light source: Osram Sirius HRI 440W discharge lamp
  • Lamp life: 1.500 Hours
  • Luminous flux: 22800 lumen, 748000lux@5m at 2°
  • Control: remote on/off via DMX
  • Ballast: switching mode power supply

Optical system

  • Beam angle: 2° to 34°

X/Y

  • Pan: 630° (4.0 Sec) or 540°(3.6 Sec), tilt: 265° (2.8 Sec)
  • 16-Bit resolution
  • Auto repositioning

Colors

  • 3 Color wheels with cmy fading + 15 color filters + open
  • 8+Open, interchangeable, indexable and bidirectional rainbow effect
  • Color bounce effect

Gobos

  • 1st gobo wheel: 18 metallic fixed gobos (5 beam reducer)
  • 2nd gobo wheel: 6 dichroic, indexable and inter-changeable rotating gobos
  • 3rd animation wheel
  • Real indexable and gobo shaking

Rigging

  • Mounting points: 4 1⁄4-turn locks
  • 2x omega brackets with 1⁄4-turn quick locks
  • Safety rope

Features

  • DMX channels: 18/20/31/32
  • Linear CMY fading
  • Color wheel: 15 colors
  • Fixed gobo wheel: 18+open
  • Rotating gobo wheel: 6+1 gobos
  • Zoom from 2° to 34°
  • Motorized auto focus
  • Full range 0-100% dimmer
  • Various strobe
  • Frost, 3 facets prism
  • Fast speed iris
  • RDM function to change dmx address, flip display, reverse x/y
  • RDM read voltage, current and powerconsumption of lamp
  • Software upgrade via DMX
  • Hibernation when lost DMX for preset time
  • Indicate temperature info of base, arm and lamp
  • Fan speed auto change according to temperature

Display

  • 2.4 Inch LCD display with english/chinese/french/spanish menu
  • Auto lock
  • Flip
  • Back-up communicating ic

Dimensions and weight

  • Dimensions (WxHxD): 411x714x258 mm
  • Weight: 27 kg

Power

  • Max power consumption: 585W
  • Power supply: electronic auto-ranging
  • Input voltage range: 100–240V, 50-60Hz
