Impact Spot 200LED

Impact Spot 200LED Specifications

Source

  • Light source: advanced 200 W white led
  • Led life: 60.000 hours
  • Luminous flux: 11000 ­lumen, 25300 lux @2.5m
  • Control: remote on/off via DMX
  • Ballast: switching mode power supply

Optical System

  • Beam angle: 14°

X/Y

  • Pan: 360° (4.0 sec) or 540°(3.58 sec)
  • Tilt: 265° (2.8 sec)
  • 16-bit resolution
  • Auto repositioning

Colors

  • 8+open, interchangeable, indexable and bidirectional rainbow effect

Gobos

  • Outside 27 mm, inside 22 mm
  • 7+ open custom interchangeable position for rotating gobo wheel
  • 7+ open fixed gobos
  • Real indexable and gobo shaking
  • Distinctive gobo animation effect

Rigging

  • Mounting points: 4 ¼-turn locks
  • 2 x Omega brackets with ¼-turn quick locks
  • Safety rope

Features

  • DMX channels: 14/16/21/24
  • Color wheel: 8+1 colors
  • Fixed gobo wheel: 7+1 gobos
  • Rotating gobo wheel: 7+1 gobos
  • Motorized focus
  • Full range 0-100% dimmer
  • Various strobe
  • Rotating effect wheel with 3 facets, 8 facets prism and frost
  • Fast speed iris
  • RDM function to change DMX address, flip display, reverse X/Y, temperature control
  • Software upgrade via DMX
  • Hibernation when lost DMX for preset time
  • Indicate temperature info of base, arm and lamp
  • Fan speed auto change according to temperature

Display

  • 2.4 inch LCD display with English/Chinese/French/Spanish menu
  • Auto lock
  • Flip
  • Back-up communicating IC

Power

  • Max power consumption: 280 W
  • Power supply: Electronic auto-ranging
  • Input voltage range: 100–240 V, 50-60 Hz

Dimension and weight

  • Fixture: 343 x 262 x 455 mm
  • Packing: 430 x 360 x 560 mm
  • Net weight: 14 kg
  • Gross weight: 16 kg
