Source

• Light source: Osram Sirius HRI 280w discharge lamp
• Lamp life: 2.000 Hours
• Luminous flux: 11165 lumen, 277200lux@20m
• Control: remote on/off via DMX
• Ballast: switching mode power supply

Optical system

• Beam angle: 1.3°

X/Y

• Pan: 630° (4.0 Sec) or 540°(3.6 Sec), tilt: 265° (2.8 Sec)
• 16-Bit resolution
• Auto repositioning

Colors

• 14+Open, interchangeable, indexable and bidirectional rainbow effect
• Color bounce effect

Gobos

• Outside 13.8Mm, inside 6mm
• 14+Open static gobos
• Real indexable and gobo shaking

Rigging

• Mounting points: 4 1⁄4-turn locks
• 2x omega brackets with 1⁄4-turn quick locks
• Safety rope

Features

• DMX channels: 10/12/13/16
• Color wheel: 14+1 colors
• Static gobo wheel: 14+open
• Motorized focus
• Full range 0-100% dimmer
• Various strobe
• Frost
• 8 Facets rotating prism
• RDM function to change DMX address, flip display, reverse X/Y
• RDM read voltage, current and powerconsumption of lamp
• Software upgrade via DMX
• Hibernation when lost DMX for preset time
• Indicate temperature info of base, arm and lamp
• Fan speed auto change according to temperature

Display

• 2.4 Inch cog display with english/chinese/french/spanish menu
• Auto lock
• Flip
• Back-up communicating ic

Power

• Max power consumption: 420w
• Power supply: electronic auto-ranging
• Input voltage range: 100–240v, 50-60hz

Dimension and weight

• Dimensions: 250x343x501mm
• Net weight: 15 kg
